The Power Team 200 Ton Hydraulic 8″ Double Acting Cylinder Center Hole RH2008 is a heavyweight performer engineered for heavy-duty lifting and pushing tasks. Its double-acting design ensures efficient operation in both directions, maximizing productivity. With an 8-inch center hole, it accommodates various applications, providing versatility on the job site. Built to withstand high pressures and demanding environments, the RH2008 delivers reliable performance, making it an essential component in industrial hydraulic systems.
SPX Power Team hydraulic technology
SPX Power Team specializes in high-pressure hydraulic technology
Power Team offers solutions to overcome your heavy lift challenge with over 96 years of experience
VIEW MORE : DOUBLE-ACTING CENTER HOLE
Power Team 200 Ton Hydraulic 8″ Double Acting Cylinder Center Hole RH2008
FEATURES:
- Double Acting
- Interchangeable piston head inserts provide versatility of application.
- 30; 60; 100 Ton Double-Acting Models Feature Threaded Collar
- Built-in safety feature prevents overpressurization of the retract circuit.
- Plated piston rod resists wear; superior packings provide high cycle life without leakage.
- Corrosion-resistant standpipe has “Power Tech” treatment.
- Each cylinder has 9796 3/8" NPTF female half couplers.
| Stroke length: | 8" |
|---|---|
| Piston rod diameter: | 7.5" |
| Series/type: | RH-Series/Center hole |
| Actuation/return: | Double acting/hydraulic return |
| Cylinder capacity: | 200 Ton |
| Pull capacity: | 75 Ton |
| Oil capacity: | 323.600"³ |
| Pull/return oil capacity: | 127.6000"³ |
| Retracted height: | 16.063" |
| Extended height: | 24.063" |
| Effective area: | 40.450"² |
| Pull cylindrical effective area: | 15.950"² |
| Tons at 10;000 PSI: | 202.30 Ton |
| Pull tons at 10;000 PSI: | 79.80 Ton |
| Max pressure: | 10;000 PSI |
| Pull internal pressure at capacity: | 9;404 PSI |
| Bore size: | 7.178" |
| Base to port: | 2.250" |
| Outside diameter: | 10.750" |
| Center hole diameter: | 4.063" |
| Insert thread size: | 6-12 |
| Cylinder top to diameter: | 3.219" |
| Cylinder material: | Steel |
| Weight: | 311lbs |
