The Power Team RHA604D is a 60-ton capacity, double-acting hydraulic cylinder with a center-hole configuration and a 4-inch stroke length, engineered for high-force applications requiring precision and durability.
The RHA604D cylinder features a compact design with a retracted height of 9.5 inchesand anextended height of 13.5 inches, yielding a 4-inch stroke. Its area is 12.31 in², supporting a maximum operating pressure of 10,000 psi, and an oil capacity of 49.2 in³ during full extension. Constructed from corrosion-resistant aluminum, the cylinder incorporates a plated piston rod and high-performance seals to ensure minimal leakage and extended cycle life. The unit includes 3/8 in NPTF female half couplers for hydraulic connections and is equipped with removable carrying handles for ease of transport.
Designed for tensioning, pulling, and anchoring operations, the RHA604D integrates a threaded collar for secure mounting and interchangeable piston head inserts to accommodate varied tooling requirements. The double-acting mechanism enables hydraulic extension and retraction, enhancing control and efficiency in repetitive tasks. The standpipe is treated with Power Tech coating for added resistance to wear and environmental degradation. This cylinder is part of Power Team’s RH series, optimized for demanding industrial and construction environments where high load capacity and compact form factor are critical.
